| Vehicle connection plug | Type 2 | |
|---|---|---|
| Mounting type | Wall | |
| Cable colour | Black | |
| Socket type | Type 2 | |
| Mechanical impact protection code | IK08 | |
| International Protection (IP) code | IP54 | |
| IEC protection class | III | |
| Cross-section connection | 5 x 10 | |
| Operating temperature (T-T) | -25 - 40 | |
| Storage temperature (T-T) | -40 - 70 | |
| Sockets quantity | 1 | |
| Sustainability compliance | Yes | |
| Wi-Fi | Yes | |
| Built-in display | No | |
| Weight | 1 kg | |
| Height | 166 mm | |
| Depth | 82 mm | |
| Width | 163 mm | |
| Charging cable length | 5 m | |
| Maximum operating current (three-phase) | 32 A | |
| Maximum operating power (three-phase) | 22 kW | |
| Voltage tolerance | 10 % | |
| Nominal frequency | 60 Hz | |
| Maximum charging power | 22000 W | |
| Number of phases | 3 | |
| Quantity per pack | 1 pc(s) | |
| LED indicators | Y | |
| Power source type | AC | |
| Housing colour | White | |
| Single-phase output voltage supported | 220, 240 | |
| Three-phase output voltage supported | 400 | |
| Sustainability certificates | CE | |
| Brūkšninis kodas | 2190001443444, 8436575273266 | |
