| HDMI in | 1 | |
|---|---|---|
| Number of HDMI outputs | 1 | |
| RJ-45 input ports | 1 | |
| RJ-45 output ports | 1 | |
| DC-in jack | Yes | |
| Remote (IR) input | 2 | |
| Remote (IR) output | 2 | |
| Video in | 1 | |
| Video out | 1 | |
| Connectivity technology | Wired | |
| Output current | 1 A | |
| External power adapter | Yes | |
| Operating voltage | 24 V | |
| Transmitter weight | 200 g | |
| Weight | 0.878 kg | |
| Receiver weight | 200 g | |
| Receiver dimensions (WxDxH) | 65 x 100 x 25 | |
| Transmitter dimensions (WxDxH) | 65 x 100 x 25 | |
| Operating temperature (T-T) | 0 - 40 | |
| Operating relative humidity (H-H) | 20 - 90 | |
| Storage temperature (T-T) | -20 - 60 | |
| Package depth | 2.03 mm | |
| Package height | 0.71 mm | |
| Package width | 1.98 mm | |
| Type | AV transmitter & receiver | |
| Maximum transfer distance | 70 m | |
| Bandwidth | 10.2 Gbit/s | |
| HDCP | Yes | |
| 3D | Yes | |
| Electrostatic Discharge (ESD) protection | 8 kV | |
| Consumer Electronics Control (CEC) support | Yes | |
| Cable types supported | Cat5e, Cat6, Cat7 | |
| Product colour | Black | |
| Supported video modes | 1080p | |
