| Connectivity technology | Wired | |
|---|---|---|
| HDCP pass-through | Yes | |
| DC-in jack | Yes | |
| HDMI in | 1 | |
| Number of HDMI outputs | 2 | |
| Remote (IR) input | 1 | |
| Remote (IR) output | 1 | |
| RJ-45 input ports | 1 | |
| RJ-45 output ports | 1 | |
| USB ports quantity | 2 | |
| HDMI version | 2.0 | |
| Bandwidth | 18 Gbit/s | |
| Maximum transfer distance | 50 m | |
| Type | AV transmitter & receiver | |
| IR pass-through | Yes | |
| Input current | 1 | |
| Operating voltage | 24 V | |
| Weight | 0.649 kg | |
| Receiver dimensions (WxDxH) | 70 x 15 x 97 | |
| Transmitter dimensions (WxDxH) | 70 x 15 x 97 | |
| Transmitter weight | 156 g | |
| Receiver weight | 151 g | |
| Operating temperature (T-T) | 0 - 40 | |
| Storage temperature (T-T) | -20 - 60 | |
| Operating relative humidity (H-H) | 20 - 90 | |
| Package type | Box | |
| Package weight | 605 g | |
| Package height | 0.7 mm | |
| Package depth | 2.2 mm | |
| Package width | 1.3 mm | |
| Certification | CE, FCC, REACH & California Proposition 65 | |
| Manual | Yes | |
| Maximum resolution | 3840 x 2160 | |
| Chipset | SIL9396, SIL9630 | |
| HDCP | Yes | |
| Extended display identification data (EDID) | Yes | |
| Maximum refresh rate | 60 Hz | |
| USB connector type | Micro-USB | |
| Material | Metal | |
| Sustainability certificates | RoHS | |
| Cables included | IR | |
| Cable types supported | Cat6, Cat5e | |
| Product colour | Black | |
