| Transmitter depth | 67 mm | |
|---|---|---|
| Receiver height | 23 mm | |
| Receiver depth | 67 mm | |
| Receiver width | 60 mm | |
| Transmitter height | 23 mm | |
| Transmitter width | 60 mm | |
| Type | Network transmitter & receiver | |
| Power note | 3.5/1.35mm DC | |
| USB 2.0 ports quantity | 2 | |
| RJ-45 ports quantity (receiver) | 1 | |
| RJ-45 ports quantity (transmitter) | 1 | |
| Data transfer rate | 480 Mbit/s | |
| Chipset | NS1021 | |
| DC-in jack | Yes | |
| Harmonized System (HS) code | 85176990 | |
| Plug and Play | Yes | |
| Maximum transfer distance | 50 m | |
| Certification | CE, UKCA, FCC, RoHS, REACH | |
| Weight | 300 kg | |
| Power over Ethernet (PoE) | Yes | |
| Output current | 0.5 A | |
| Output voltage | 24 | |
| Input current | 0.25 | |
| Operating temperature (T-T) | 0 - 70 | |
| Storage temperature (T-T) | -20 - 80 | |
| Operating relative humidity (H-H) | 0 - 90 | |
| Storage relative humidity (H-H) | 0 - 90 | |
| Manual | Yes | |
| Package width | 185 mm | |
| Package depth | 140 mm | |
| Package height | 55 mm | |
| Package weight | 400 g | |
| Package type | Box | |
| Included power plug types | EU, UK, US, AU | |
| Cables included | USB Type-A to USB Type-B | |
| Cable types supported | Cat5e, Cat6, Cat5 | |
| Product colour | Black | |
| Housing material | Metal | |
| LED indicators | Y | |
