| Switch layer | L2 | |
|---|---|---|
| 10G support | No | |
| Full duplex | Yes | |
| Flow control support | Yes | |
| Broadcast storm control | Yes | |
| Auto MDI/MDI-X | Yes | |
| Auto-negotiation | Yes | |
| Store-and-forward | Yes | |
| Rack mounting | Yes | |
| Stackable | Yes | |
| Wall mountable | Yes | |
| DIN rail mounting | Yes | |
| Plug and Play | Yes | |
| Power over Ethernet (PoE) | No | |
| Switch type | Unmanaged | |
| Package weight | 488 g | |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) | |
| International Protection (IP) code | IP30 | |
| Certification | UL 60950‑1CEFCC | |
| Harmonized System (HS) code | 85176990 | |
| DC input voltage | 12 - 58 | |
| Operating temperature (T-T) | -40 - 75 | |
| Storage temperature (T-T) | -40 - 85 | |
| Operating relative humidity (H-H) | 5 - 95 | |
| Pallet gross weight (sea) | 330660 g | |
| Relay outputs | 1 | |
| MAC address table | 1000 entries | |
| Mean time between failures (MTBF) | 219000 h | |
| Shipping (inner) case height | 200 mm | |
| Shipping (inner) case width | 305 mm | |
| Shipping (inner) case length | 430 mm | |
| Shipping (inner) case net weight | 5780 g | |
| Products per shipping (inner) case | 10 pc(s) | |
| Pallet gross weight (air) | 226440 g | |
| Master (outer) cases per pallet (air) | 36 pc(s) | |
| Products per pallet (air) | 360 pc(s) | |
| Pallet gross length | 1200 mm | |
| Pallet gross width | 1100 mm | |
| Pallet height (air) | 1350 mm | |
| Basic switching RJ-45 Ethernet ports quantity | 5 | |
| Master (outer) cases per pallet (sea) | 54 pc(s) | |
| Products per pallet (sea) | 540 pc(s) | |
| Pallet height (sea) | 1950 mm | |
| Shipping (inner) case gross weight | 5790 g | |
| Power consumption (typical) | 0.95 W | |
| Power consumption (max) | 1.56 W | |
| Width | 29.1 mm | |
| Depth | 89.4 mm | |
| Height | 109.2 mm | |
| Weight | 320 kg | |
| Package width | 140 mm | |
| Package depth | 178 mm | |
| Package height | 83 mm | |
| Networking standards | IEEE 802.3x | |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 100BASE-T | |
| Product colour | Black | |
| Brūkšninis kodas | 0790069441271, 7900694412710 | |
