| Total power | 550 W | |
|---|---|---|
| Power Factor Correction (PFC) type | Active | |
| Power factor | 0.9 | |
| Combined power (+3.3V) | 100 W | |
| Combined power (+12V) | 546 W | |
| Combined power (+5V) | 100 W | |
| Combined power (-12V) | 3.6 W | |
| Combined power (+5Vsb) | 12.5 W | |
| Max output current (+3.3V) | 20 A | |
| Max output current (+12V) | 45.5 A | |
| Max output current (+5V) | 20 A | |
| Max output current (-12V) | 0.3 A | |
| Max output current (+5Vsb) | 2.5 A | |
| Input current | 8 | |
| AC input frequency | 47 - 63 | |
| AC input voltage | 100 - 240 | |
| Motherboard power connector | 20+4 pin ATX | |
| Floppy drive power connector | 1 | |
| Number of SATA power connectors | 6 | |
| Peripheral (Molex) power connectors (4-pin) | 3 | |
| PCI Express power connectors (6+2 pin) | 2 | |
| Cabling type | Modular | |
| Motherboard power cable length | 650 mm | |
| EPS power connector (4+4 pin) | Yes | |
| Purpose | PC/Server | |
| 80 PLUS certification | 80 PLUS Bronze | |
| Certification | EACFCCCB | |
| Bearing technology | FDB | |
| ATX version | 2.3 | |
| Power supply unit (PSU) form factor | ATX | |
| Fan diameter | 120 mm | |
| Number of fans | 1 fan(s) | |
| Cooling type | Active | |
| Sustainability compliance | Yes | |
| Weight | 2.347 kg | |
| Height | 86 mm | |
| Depth | 140 mm | |
| Width | 150 mm | |
| Package depth | 3.1 mm | |
| Package height | 1.3 mm | |
| Package width | 2.25 mm | |
| Package weight | 2170 g | |
| Harmonized System (HS) code | 84733020 | |
| Power protection features | Over current, Over voltage, Overheating, Overload, | |
| SATA power cable length | 500, 150 | |
| Peripheral (Molex) power cable length | 500, 150 | |
| Product colour | Black | |
| Sustainability certificates | RoHS, ErP, CE | |
