• 80 PLUS certification
    80 PLUS Bronze
  • AC input frequency
    50 - 60 Hz
  • AC input voltage
    100 - 240 V
  • ATX power connector (20+4 pin)
    Y
  • ATX version
    2.31
  • Bearing technology
    HDB
  • Cabling type
    Non-Modular
  • Certification
    CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE
  • Combined power (+12V)
    648 W
  • Combined power (+3.3V)
    108 W
  • Combined power (+5V)
    108 W
  • Combined power (+5Vsb)
    12.5 W
  • Combined power (-12V)
    3.6 W
  • Cooling type
    Active
  • CPU P4 connector (4-pin)
    1
  • CPU power cable length
    60 cm
  • CPU power connector (4+4 pin)
    Y
  • Depth
    150 mm
  • Fan diameter
    12 cm
  • Fan location
    Top
  • Floppy disk drive connector
    Y
  • Garantija
    24
  • Height
    86 mm
  • Input current
    9 - 4 A
  • Max output current (+12V)
    54 A
  • Max output current (+3.3V)
    18 A
  • Max output current (+5V)
    15 A
  • Max output current (+5Vsb)
    2.5 A
  • Max output current (-12V)
    0.3 A
  • Maximum input current (@110V)
    9 A
  • Maximum input current (@220V)
    4 A
  • Mean time between failures (MTBF)
    100000 h
  • Motherboard power cable length
    60 cm
  • Motherboard power connector
    20+4 pin ATX
  • Noise level
    39 dB
  • Noise level (full-load mode, 100%)
    39 dB
  • Noise level (quiet mode, 50%)
    29 dB
  • Noise level (silent mode, <30%)
    20 dB
  • Number of fans
    1 fan(s)
  • Number of SATA power connectors
    6
  • On/off switch
    Y
  • Package type
    Box
  • PCI Express power cable length
    65 cm
  • PCI Express power connectors (6+2 pin)
    4
  • Peripheral (Molex) power cable length
    150
  • Peripheral (Molex) power connectors (4-pin)
    3
  • Power Factor Correction (PFC) type
    Active
  • Power management
    Y
  • Power protection features
    Over power
  • Power supply unit (PSU) form factor
    ATX
  • Product colour
    Black
  • Purpose
    PC
  • SATA power cable length
    500 mm
  • Total power
    650 W
  • Width
    140 mm
  • *Garantija
    24
  • Brūkšninis kodas
    0194276368992, 0194276369050, 0194276369067, 0194276369128, 0813567025573, 4719331550295, 8135670255732

PREKĖS SAVYBĖS

Produkto tipasMaitinimo blokas
Formos faktoriusATX12V 2.31
Ryšys
PCI Express jungtys (8 kontaktų)4
Serial ATA jungtys6
Pagrindinės plokštės maitinimo jungtysATX12V (20+4 kontaktų), ATX12V / EPS12V (4+4 Pins)
Floppy1
Periferinės jungtys (4 kontaktų)3
Maitinimas
Tinklo įtampa100 - 240 Volt
Maitinimo tinklo dažnis50 - 60 Hz
Srovė + 12 V54 A
Kombinuotas 3,3 V/5 V maitinimas108 Watt
Kombinuotas maitinimas 12V648 Watt
+3,3 V įtampa18
+5V įtampa15
Įtampa -12V0.3 A
Įtempimas +5VSB2.5 A
Funkcijos
Saugos funkcijos (PSU apsauga)Apsauga nuo maitinimo pertekliaus (OPP), Apsauga nuo žemos įtampos (UVP), Apsauga nuo viršįtampio (OVP), Apsauga nuo trumpojo jungimo (SCP), Apsauga nuo srovės pertekliaus (OCP)
Aušinimas ir ventiliatoriai
Aušinimo sistemaAktyvus
Max ventiliatoriai1
Ventiliatoriaus skersmuo120 mm
Galios koeficiento koregavimasAktyvus
Matmenys ir svoris
SpalvaJuoda
Matmenys15 x 14 x 8,6 cm
Brūkšninis kodas0194276368992, 0194276369050, 0194276369067, 0194276369128, 0813567025573, 4719331550295, 8135670255732
