| Model | Z790 EAGLE (rev. 1.0) | |
|---|---|---|
| Garantija | 36 | |
| Form Factor | ATX | |
| Socket | LGA1700 | |
| Memory type | DDR5 | |
| Memory slots | 4 | |
| RAID | SATA 0, 1, 5, 10 NVMe 0, 1, 5, 10 | |
| CnCode (CnCode) | 84733020 | |
| Chipset | Intel Z790 | |
| Input/Output connectors (RJ45) | 1 | |
| Frequency speed | 4400/5200/5600/7400/7000/6400/6600/7200/6200/5800/ | |
| Integrated LAN | 2.5 Gigabit | |
| Input/Output connectors (USB 3.2) | 6 | |
| Input/Output connectors (HDMI) | 1 | |
| Input/Output connectors (USB-C) | 1 | |
| Input/Output connectors (USB 2.0) | 6 | |
| Input/Output connectors (DisplayPort) | 1 | |
| Input/Output connectors (Audio port) | 3 | |
| Input/Output connectors (Optical S/PDIF) | 1 | |
| Interface (SATA) | Yes | |
| Expansion slots (PCI-Express 5.0 16x) | 1 | |
| Expansion slots (M.2) | 3 | |
| Interface (USB 2.0) | Yes | |
| Interface (USB-C) | Yes | |
| Integrated video | Depending on CPU | |
| Integrated audio | Yes | |
| Interface (USB 3.2) | Yes | |
| Expansion slots (PCI-Express 4.0 4x) | 1 | |
| TPM | Header | |
| Input/Output connectors (PS/2) | 1 | |
| Expansion slots (PCI-Express 3.0 1x) | 3 | |
| Vendor Homepage | www.gigabyte.com/Motherboard/Z790-EAGLE-rev-10 kf | |
| Unit Net Weight | 0.7 kg | |
| Unit Box Width | 0.081 | |
| Unit Box Length | 0.271 | |
| Unit Box Height | 0.342 | |
| Category Code | MBI | |
| Brūkšninis kodas | 4719331860981 | |
