| Motherboard form factor | ATX | |
|---|---|---|
| Motherboard chipset | Intel B560 | |
| Component for | PC | |
| Audio output channels | 7.1 | |
| Motherboard chipset family | Intel | |
| Harmonized System (HS) code | 84733020 | |
| Number of mounting holes | 9 | |
| Processor manufacturer | Intel | |
| Maximum number of SMP processors | 1 | |
| Processor socket | LGA 1200 | |
| Number of memory slots | 4 | |
| Maximum internal memory | 128 GB | |
| Non-ECC | Yes | |
| Memory channels | Dual-channel | |
| Unbuffered memory | Yes | |
| Memory slots type | DIMM | |
| Number of M.2 (M) slots | 3 | |
| PCI Express x16 slots | 2 | |
| PCI Express x1 (Gen 3.x) slots | 1 | |
| Wi-Fi | No | |
| Ethernet LAN | Yes | |
| Number of SATA III connectors | 6 | |
| TPM connector | Yes | |
| 12V power connector | Yes | |
| Chassis intrusion connector | Yes | |
| CPU fan connector | Yes | |
| ATX Power connector (24-pin) | Yes | |
| Front panel audio connector | Yes | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 | |
| Number of chassis fan connectors | 5 | |
| USB 2.0 connectors | 2 | |
| DisplayPorts quantity | 1 | |
| USB 2.0 ports quantity | 4 | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 | |
| Ethernet LAN (RJ-45) ports | 2 | |
| Digital audio optical out | 1 | |
| S/PDIF out port | Yes | |
| HDMI version | 2.0b | |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 | |
| HDMI ports quantity | 1 | |
| Supported storage drive types | HDD & SSD | |
| Clear CMOS jumper | Yes | |
| Depth | 244 mm | |
| Width | 305 mm | |
| Audio chip | Realtek ALC897 | |
| DisplayPort version | 1.4 | |
| Drivers included | Yes | |
| Windows operating systems supported | Windows 10 x64 | |
| Compatible processor series | Intel Pentium, Intel Core i9, Intel Core i7, Intel | |
| Supported memory types | DDR4-SDRAM | |
| Supported memory clock speeds | 2933, 5066, 4600, 4266, 4000, 3200, 2666 | |
| Parallel processing technology support | 2-Way CrossFireX | |
| LAN controller | Realtek RTL8125B, Intel I219-V | |
| Ethernet interface type | Gigabit Ethernet, 2.5 Gigabit Ethernet | |
| Supported storage drive interfaces | SATA III, M.2 | |
| Cables included | SATA | |
| Brūkšninis kodas | 4719072802912 | |
