| Thermal Design Power (TDP) | 105 W | |
|---|---|---|
| Component for | Server/workstation | |
| Processor family | Intel® Xeon® Gold | |
| Processor model | 5120 | |
| Processor codename | Skylake | |
| Processor socket | FCLGA3647 | |
| Processor code | SR3GD | |
| Processor boost frequency | 3.2 GHz | |
| Processor cores | 14 | |
| Processor threads | 28 | |
| Processor cache type | L3 | |
| Stepping | M0 | |
| Box | Yes | |
| Processor lithography | 14 nm | |
| Cooler included | Yes | |
| Processor ARK ID | 120474 | |
| Processor base frequency | 2.2 GHz | |
| Processor manufacturer | Intel | |
| Intel® Turbo Boost Technology | 2.0 | |
| Intel® AES New Instructions (Intel® AES-NI) | Yes | |
| Enhanced Intel SpeedStep Technology | Yes | |
| Intel Trusted Execution Technology | Yes | |
| Intel VT-x with Extended Page Tables (EPT) | Yes | |
| Intel TSX-NI | Yes | |
| Intel 64 | Yes | |
| Intel Virtualization Technology (VT-x) | Yes | |
| Intel TSX-NI version | 1.00 | |
| Conflict-Free processor | Yes | |
| Intel Turbo Boost Max Technology 3.0 | No | |
| Intel® Optane™ Memory Ready | No | |
| Intel® Speed Shift Technology | Yes | |
| Intel® Run Sure Technology | Yes | |
| Mode-based Execute Control (MBE) | Yes | |
| Intel® vPro™ Platform Eligibility | Yes | |
| Intel® Transactional Synchronization Extensions | Yes | |
| AVX-512 Fused Multiply-Add (FMA) units | 1 | |
| Intel® Volume Management Device (VMD) | Yes | |
| On-board graphics card | No | |
| Execute Disable Bit | Yes | |
| Scalability | 4S | |
| Embedded options available | No | |
| Maximum number of PCI Express lanes | 48 | |
| PCI Express CEM revision | 3.0 | |
| Export Control Classification Number (ECCN) | 5A992C | |
| Harmonized System (HS) code | 85423119 | |
| Market segment | Server | |
| Mode-based Execute Control (MBE) version | 1.00 | |
| Intel® Speed Shift Technology version | 1.00 | |
| Intel® Run Sure Technology version | 1.00 | |
| Intel® Volume Management Device (VMD) version | 1.00 | |
| Launch date | Q3'17 | |
| Status | Launched | |
| Product type | Processor | |
| Processor brand name | Intel Xeon GoldIntel Xeon Gold Processor | |
| Product family | Intel Xeon Processors | |
| Maximum memory | 768 GB | |
| Last change | 63903513 | |
| Memory speed (max) | 2400 MHz | |
| Number of UPI links | 2 | |
| Maximum internal memory supported by processor | 768 GB | |
| Memory channels | Hexa-channel | |
| ECC | Yes | |
| Processor package size | 76mm x 56.5mm | |
| Tcase | 81 °C | |
| Package type | Retail box | |
| Processor operating modes | 64-bit | |
| Supported instruction sets | AVX-512, AVX 2.0, AVX, SSE4.2 | |
| PCI Express slots version | 3.0 | |
| Supported memory types | DDR4-SDRAM | |
| Memory clock speeds supported by processor | 2400 | |
| Memory types supported by processor | DDR4-SDRAM | |
| Brūkšninis kodas | 5032037104111 | |
