Processor family
Intel® Core™ i7
-
Processor model
i7-13700K
-
Processor codename
Raptor Lake
-
Processor socket
LGA 1700
-
Processor boost frequency
5.4 GHz
-
Processor cores
16
-
Processor threads
24
-
Processor cache
30 MB
-
Processor cache type
Smart Cache
-
Stepping
B0
-
Bus type
DMI4
-
Box
Yes
-
Performance cores
8
-
Efficient cores
8
-
Performance-core boost frequency
5.3 GHz
-
Performance-core base frequency
3.4 GHz
-
Efficient-core boost frequency
4.2 GHz
-
Efficient-core base frequency
2.5 GHz
-
Processor base power
125 W
-
Maximum turbo power
253 W
-
Maximum number of DMI lanes
8
-
Processor manufacturer
Intel
-
Intel® Turbo Boost Technology
2.0
-
Intel® Quick Sync Video Technology
Yes
-
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
-
Intel® AES New Instructions (Intel® AES-NI)
Yes
-
Enhanced Intel SpeedStep Technology
Yes
-
Intel Trusted Execution Technology
Yes
-
Intel VT-x with Extended Page Tables (EPT)
Yes
-
Intel® Secure Key
Yes
-
Intel 64
Yes
-
Intel® OS Guard
Yes
-
Intel Virtualization Technology (VT-x)
Yes
-
Intel Turbo Boost Max Technology 3.0
Yes
-
Intel® Speed Shift Technology
Yes
-
Intel® Turbo Boost Max Technology 3.0 frequency
5.4 GHz
-
Intel® Control-flow Enforcement Technology (CET)
Yes
-
Intel® Thread Director
Yes
-
Intel® Boot Guard
Yes
-
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
-
Intel® Volume Management Device (VMD)
Yes
-
Mode-based Execute Control (MBE)
Yes
-
Intel® Standard Manageability (ISM)
Yes
-
On-board graphics card ID
0xA780
-
On-board graphics card base frequency
300 MHz
-
On-board graphics card dynamic frequency (max)
1600 MHz
-
Number of displays supported (on-board graphics)
4
-
Number of execution units
32
-
Multi-Format Codec Engines
2
-
On-board graphics card
Yes
-
Discrete graphics card
No
-
On-board graphics card model
Intel UHD Graphics 770
-
On-board graphics card DirectX version
12.0
-
On-board graphics card OpenGL version
4.5
-
Discrete graphics card model
Not available
-
On-board graphics card maximum resolution (HDMI)
4096 x 2160
-
Execute Disable Bit
Yes
-
Idle States
Yes
-
Thermal Monitoring Technologies
Yes
-
Scalability
1S
-
CPU configuration (max)
1
-
Embedded options available
No
-
Maximum number of PCI Express lanes
20
-
Direct Media Interface (DMI) Revision
4.0
-
Market segment
Desktop
-
Harmonized System (HS) code
8542310001
-
Export Control Classification Number (ECCN)
5A992C
-
OpenCL version
3.0
-
Target market
Gaming, Content Creation
-
Launch date
Q4'22
-
Status
Launched
-
Maximum internal memory supported by processor
128 GB
-
Memory bandwidth (max)
89.6 GB/s
-
ECC
Yes
-
Memory channels
Dual-channel
-
Tjunction
100 °C
-
L2 cache
24576 KB
-
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
-
Package type
Retail box
-
Processor operating modes
64-bit
-
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a,
-
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
-
PCI Express slots version
4.0, 5.0
-
PCI Express configurations
1x16+1x4, 2x8+1x4
-
Use conditions
PC/Client/Tablet, Workstation
-
Memory types supported by processor
DDR4-SDRAM, DDR5-SDRAM
-
Brūkšninis kodas
0735858526678, 0751492776989, 2220008293060, 5032037258708, 5032037258722, 7514927769894
