| Processor family | Intel® Core™ i7 |
|---|---|
| Processor model | i7-13700KF |
| Processor codename | Raptor Lake |
| Processor socket | LGA 1700 |
| Processor boost frequency | 5.4 GHz |
| Processor cores | 16 |
| Processor threads | 24 |
| Processor cache | 30 MB |
| Processor cache type | Smart Cache |
| Stepping | B0 |
| Box | Yes |
| Efficient cores | 8 |
| Performance cores | 8 |
| Processor manufacturer | Intel |
| Maximum number of DMI lanes | 8 |
| Maximum turbo power | 253 W |
| Processor base power | 125 W |
| Efficient-core base frequency | 2.5 GHz |
| Efficient-core boost frequency | 4.2 GHz |
| Performance-core base frequency | 3.4 GHz |
| Performance-core boost frequency | 5.3 GHz |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel 64 | Yes |
| Intel® OS Guard | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Thread Director | Yes |
| Intel® Boot Guard | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.4 GHz |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Maximum number of PCI Express lanes | 20 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Harmonized System (HS) code | 8542310001 |
| Market segment | Desktop |
| Launch date | Q4'22 |
| Status | Launched |
| Memory bandwidth (max) | 89.6 GB/s |
| Maximum internal memory supported by processor | 128 GB |
| Memory channels | Dual-channel |
| Tjunction | 100 °C |
| L2 cache | 24576 KB |
| Processor operating modes | 64-bit |
| Supported instruction sets | SSE4.2, SSE4.1, AVX 2.0 |
| PCI Express slots version | 5.0, 4.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Use conditions | PC/Client/Tablet |
| Memory types supported by processor | DDR5-SDRAM, DDR4-SDRAM |
