| Wi-Fi | No | |
|---|---|---|
| Height | 48 mm | |
| Depth | 225 mm | |
| Width | 260 mm | |
| Weight | 1 kg | |
| Video input channels | 4 channels | |
| HDD Capacity | 0 GB | |
| HDMI ports quantity | 1 | |
| DC-in jack | Yes | |
| Output Voltage | 12 V | |
| Power | 18 W | |
| Maximum resolution | 1920 x 1080 pixels | |
| Product colour | Black | |
| Guarantee | F024M | |
| Power consumption (typical) | 10 W | |
| Operating temperature (T-T) | -10 - 55 C | |
| USB 2.0 ports quantity | 2 | |
| Operating relative humidity (H-H) | 10 - 90% | |
| Ethernet LAN (RJ-45) ports | 1 | |
| Ethernet LAN data rates | 100 10 | |
| Supported network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, S | |
| Rack mounting | Yes | |
| Rack capacity | 1U | |
| Maximum storage capacity | 6 TB | |
| HDD interface | SATA II SATA III SATA | |
| VGA (D-Sub) output ports | 1 | |
| HDMI output | Yes | |
| Number of HDDs supported | 1 | |
| Video codecs | H.265+/H.265/ H.264+/H.264 | |
| Supported resolutions | 1920 1080, 1600 1200, 1280 1024, 1280 720, 1024 76 | |
| Input bandwidth | 40 Mbit/s | |
| Output bandwidth | 60 Mbit/s | |
